ULTRA LONG 48V

Categories: LED STRIP LIGHTING

Illuminate long areas safely and easily with this LED strip light
With a 30-meter continuous run, minimal lighting decay, and low-voltage 48V input, it requires fewer power feeds
Available in custom lengths or 50/30-meter IP20/IP67 options, it’s perfect for use in bulkheads, corridors, bridges, and more
Enjoy ultra-long runs with small step/cut lengths

Basic Parameters
Size	IP20: 10mm x 1.6mm x 50,000 IP67: 10mm x 1.6mm x 30,000 or Custom
Input Voltage	48VDC
Input Current	0.183A/1m and 4.33A/30m
Max Power	9.6W
Lifetime	L90 >36,000 hours
Connection Tails	Custom / 2x2m for 5m reel
Chips/m	120
Colour / CCT	3000K, 4000K
Bin Step (SDCM)	1 bin 2 step MacAdam ellipse
IP Rating	>IP20/IP67
CRI	>90
Energy Efficiency Class	>A+
Warranty	5 years
Cutting Increment	6 leds / 50mm (1.97")
Control	0-10V
Beam Angle	120° Beam

Colour/CCT	Typical Power	Cutting increment	LM/M	Cont. Max Run
3000K	8.8W/1m and 207.8W/30m	33.33mm	830	3m
4000K	8.8W/1m and 207.8W/30m	33.33mm	860	3m
