ULTRA LONG 48V

ULTRA LONG 48V

Categories:
  • Illuminate long areas safely and easily with this LED strip light
  • With a 30-meter continuous run, minimal lighting decay, and low-voltage 48V input, it requires fewer power feeds
  • Available in custom lengths or 50/30-meter IP20/IP67 options, it’s perfect for use in bulkheads, corridors, bridges, and more
  • Enjoy ultra-long runs with small step/cut lengths
Basic Parameters
SizeIP20: 10mm x 1.6mm x 50,000 IP67: 10mm x 1.6mm x 30,000 or Custom
Input Voltage48VDC
Input Current0.183A/1m and 4.33A/30m
Max Power9.6W
LifetimeL90 >36,000 hours
Connection TailsCustom / 2x2m for 5m reel
Chips/m120
Colour / CCT3000K, 4000K
Bin Step (SDCM)1 bin 2 step MacAdam ellipse
IP Rating>IP20/IP67
CRI>90
Energy Efficiency Class>A+
Warranty5 years
Cutting Increment6 leds / 50mm (1.97")
Control0-10V
Beam Angle120° Beam
Colour/CCTTypical PowerCutting incrementLM/MCont. Max Run
3000K8.8W/1m and 207.8W/30m33.33mm8303m
4000K8.8W/1m and 207.8W/30m33.33mm8603m
