| Basic Parameters | |
|---|---|
| Size | IP20: 12mm x 2.1mm x 5000 IP65: custom |
| Input Voltage | 24VDC |
| Input Current | 0.7A/1m and 2.91A/5m |
| Max Power | 19.2W(1m) |
| Lifetime | L90 >36,000 hours |
| LED per/m | |
| Chips/m | 60 |
| Colour / CCT | 2700K, 4000K, 6000K |
| Bin Step (SDCM) | 1 bin 5 step MacAdam ellipse |
| IP Rating | >IP20/IP65 |
| CRI | >90 |
| Energy Efficiency Class | >A+ |
| Warranty | 5 years |
| Cutting Increment | 6 leds / 100mm (3.94") |
| Control | 0-10V |
| Beam Angle | 170° Beam |
| Colour/CCT | Typical Power | Cutting Unit | LM/M | Cont. Max Run |
|---|---|---|---|---|
| 2700K | 16.8W/1m and 69.84W/5m | No cutting | 900 | 3m |
| 4000K | 16.8W/1m and 69.84W/5m | 6 leds / 100mm (3.94") | 950 | 3m |
| 6000K | 16.8W/1m and 69.84W/5m | 6 leds / 100mm (3.94") | 980 | 3m |
COLOUR TEMPERATURE
