| Field | : | Field | : |
|---|---|---|---|
| Input Type | 300mm AC Cable | Dimming Function | No |
| Input Voltage | 90 ~ 305VAC | Dimming / Control Options | N/A |
| Input Current | 0.75A / 230VAC, 0.7A / 277VAC | Control Options | N/A |
| Output Voltage | 24V | Prescribed Electrical Item | Yes |
| Output Current | 6.3A | SELV | Yes |
| Constant Current Region | 12 ~ 24V | Efficiency | 93.00% |
| Rated Output Power | 151.2W | Operating Temperature Range | Tcase= -40 ~ +90ºC |
| Output Type | Constant Voltage / Constant Current | Warranty | 7 Years |
| Output Connector | 300mm cable | Approvals | CE, CB, RCM |
| Output Voltage Adjustment | 22 ~ 27V | IP Rating / Environmental Protection | IP65 |
| Output Current Adjustment Range | 3.8 ~ 6.3A | Dimensions | 228*68*38.8mm |
| Auxiliary Power | N/A | Recommended for New Designs | Yes |
