| Basic Parameters | |
|---|---|
| Size | 12mm x 20mm x 10000mm (or custom) |
| Input Voltage | DC24V |
| Input Current | Table Data |
| Max Power | 10W/1m or 50W/5m |
| Lifetime | >30,000 hours |
| LED per/m | |
| Continuous Max Run | 5 metres / custom |
| Colour / CCT | 2700K, 3000K, 4000K, 65000K, CCT, RGB+CCT |
| Bin Step (SDCM) | |
| IP Rating | >IP67 |
| CRI | >90 |
| Energy Efficiency Class | >A+ |
| Warranty | 5 years or 30,000 hours |
| Cutting Increment | |
| Control | Phase-cut leading & trailing / 0-10V / 1-10V /PWM / DMX / DALI |
| Beam Angle | 60°, 90°, 170° |
| Colour/CCT | Typical Power | Cutting Unit | LM/M | Cont. Max Run |
|---|---|---|---|---|
| 2700K | 10W/1M | No cutting | 820 | 4 x 1M |
| 3000K | 10W/1M | No cutting | 900 | 4 x 1M |
| 4000K | 10W/1M | No cutting | 980 | 4 x 1M |
| 6500K | 10W/1M | No cutting | 1000 | 4 x 1M |
| RGB+CCT | 10W/1M | No cutting | 520-530 | 4 x 1M |
| CCT | 10W/1M | No cutting | 620-630 | 4 x 1M |
LIGHT AND BEND DIRECTION
