| Basic Parameters | |
|---|---|
| Size | IP20: 12mm x 2.1 mm x 50000 or custom |
| Input Voltage | 24VDC |
| Input Current | 0.683A/1m and 3.1A/5m |
| Max Power | 18W |
| Lifetime | L90 >36,000 hours |
| Connection Tails | Custom / 2x2m for 5m reel |
| Chips/m | 240 |
| Colour / CCT | RGB |
| Bin Step (SDCM) | 1 bin 2 step MacAdam ellipse |
| IP Rating | >IP20/IP65 |
| CRI | >90 |
| Energy Efficiency Class | >A+ |
| Warranty | 5 years |
| Cutting Increment | 6 leds / 25mm |
| Control | RF/DMX/Other compatible control systems |
| Beam Angle | 170° Beam |
| Colour/CCT | Typical Power | Cutting Unit | LM/M | Cont. Max Run |
|---|---|---|---|---|
| RGB 20 | 16.4W/1m and 74.4W/5M | No cutting | N/A | 3m |
| RGB 65 | 16.4W/1m and 74.4W/5M | 6 leds / 100mm (3.94") | N/A | 3m |
